1 设计依据
《钢结构设计规范》 （GB50017-2017 ）
《建筑结构荷载规范》 （GB50009-2012）
《建筑抗震设计规范》 （GB50011-2016 ）
《建筑地基基础设计规范》 （GB50007-2011）
《钢结构焊接规范》 （GB50661-2011）
《钢结构高强度螺栓连接技术规程》 （JGJ82-2011）
计算简图 (圆表示支座，数字为节点号)
节点编号图
单元编号图
各单元信息如下表：
注：等肢单角钢的2、3轴分别对应u、v轴
|
单元号 |
截面名称 |
长度(m) |
面积(mm2) |
绕2轴 惯性矩(x104mm4 ) |
绕3轴 惯性矩(x104mm4 ) |
绕2轴计 算长度 系数 |
绕3轴计 算长度 系数 |
i节点 释放 |
j节点 释放 |
|
1 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
2 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
3 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
4 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
5 |
矩50x50x3x3 |
0.700 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
6 |
矩50x50x3x3 |
1.562 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
7 |
矩50x50x3x3 |
1.560 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
8 |
矩50x50x3x3 |
1.569 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
9 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
10 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
11 |
矩50x50x3x3 |
1.568 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
12 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
13 |
矩50x50x3x3 |
1.589 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
14 |
矩50x50x3x3 |
1.567 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
15 |
矩50x50x3x3 |
1.525 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
16 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
17 |
矩50x50x3x3 |
1.602 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
18 |
矩50x50x3x3 |
1.542 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
19 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
20 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
21 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
22 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
23 |
矩50x50x3x3 |
0.700 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
24 |
矩60x60x4x4 |
1.081 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
25 |
矩60x60x4x4 |
1.323 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
26 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
27 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
28 |
矩60x60x4x4 |
1.106 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
29 |
矩60x60x4x4 |
1.323 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
30 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
31 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
32 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
33 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
34 |
矩60x60x4x4 |
1.323 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
35 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
36 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
37 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
38 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
39 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
40 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
41 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
42 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
43 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
44 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
45 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
46 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
47 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
48 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
49 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
50 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
51 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
52 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
53 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
54 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
55 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
56 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
57 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
58 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
59 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
60 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
61 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
62 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
63 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
64 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
65 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
66 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
67 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
68 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
69 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
70 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
71 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
72 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
73 |
矩60x60x4x4 |
1.321 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
74 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
75 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
76 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
77 |
矩60x60x4x4 |
0.001 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
78 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
79 |
矩60x60x4x4 |
1.335 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
80 |
矩60x60x4x4 |
1.320 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
81 |
矩60x60x4x4 |
0.001 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
82 |
矩50x50x3x3 |
0.523 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
83 |
矩50x50x3x3 |
1.560 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
84 |
矩50x50x3x3 |
1.562 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
85 |
矩50x50x3x3 |
1.560 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
86 |
矩50x50x3x3 |
1.562 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
87 |
矩50x50x3x3 |
1.560 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
88 |
矩50x50x3x3 |
1.569 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
89 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
90 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
91 |
矩50x50x3x3 |
1.568 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
92 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
93 |
矩50x50x3x3 |
1.589 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
94 |
矩50x50x3x3 |
1.567 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
95 |
矩50x50x3x3 |
1.525 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
96 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
97 |
矩50x50x3x3 |
1.602 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
98 |
矩50x50x3x3 |
1.542 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
99 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
100 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
101 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
102 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
103 |
矩50x50x3x3 |
0.700 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
104 |
矩50x50x3x3 |
1.562 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
105 |
矩50x50x3x3 |
1.560 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
106 |
矩50x50x3x3 |
1.569 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
107 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
108 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
109 |
矩50x50x3x3 |
1.568 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
110 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
111 |
矩50x50x3x3 |
1.589 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
112 |
矩50x50x3x3 |
1.567 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
113 |
矩50x50x3x3 |
1.525 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
114 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
115 |
矩50x50x3x3 |
1.602 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
116 |
矩50x50x3x3 |
1.542 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
117 |
矩50x50x3x3 |
0.700 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
118 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
119 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
120 |
矩50x50x3x3 |
1.577 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
121 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
122 |
矩50x50x3x3 |
1.542 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
123 |
矩50x50x3x3 |
1.602 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
124 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
125 |
矩50x50x3x3 |
1.525 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
126 |
矩50x50x3x3 |
1.567 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
127 |
矩50x50x3x3 |
1.589 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
128 |
矩50x50x3x3 |
1.551 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
129 |
矩50x50x3x3 |
1.569 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
130 |
矩50x50x3x3 |
1.538 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
131 |
矩50x50x3x3 |
1.564 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
132 |
矩50x50x3x3 |
1.568 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
133 |
矩50x50x3x3 |
1.560 |
564 |
20.85 |
20.85 |
1.000 |
1.000 |
--- |
--- |
|
134 |
矩60x60x4x4 |
1.081 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
|
135 |
矩60x60x4x4 |
1.106 |
896 |
47.07 |
47.07 |
1.000 |
1.000 |
--- |
--- |
关注微信公众号
联系项目总监
